Multipurpose Hose 20 Bar (Air/Water)
Softwall hose with exceptional versatility and performance, making them ideal for various industrial uses such as conveying air, water, and mild chemicals.
Tube: Black color of NBR blend compound. Oil and non-aggressive chemical resistant.
Cover: Red color of EPDM blend compound. Oil, abrasion and weather resistant.
Reinforcement: High tensile synthetic yarn.
Temperature: -20°C to +80°C
Safety Factor: 3:1
Code | Nominal Inch | I.D (mm) | O.D (mm) | Weight (Kg/m) |
|---|---|---|---|---|
| RMAW20064014 | 1/4” | 6.4 | 14 | 0.210 |
| RMAW20008015 | 5/16” | 8 | 15 | 0.221 |
| RMAW20095017 | 3/8” | 9.5 | 17 | 0.275 |
| RMAW20127020 | 1/2” | 12.7 | 20 | 0.384 |
| RMAW20016025 | 5/8” | 16 | 25 | 0.504 |
| RMAW20019029 | 3/4” | 19 | 29 | 0.665 |
| RMAW20022032 | 7/8” | 22 | 32 | 0.747 |
| RMAW20254036 | 1” | 25.4 | 36 | 0.904 |
Working Pressure (bar)
20
Burst Pressure (bar)
60
Max Length (m)
100
